Ronstan Wide Dee Shackles [Pack of 2]
Ronstan
$65.25 - $107.26
(No reviews yet)
Write a Review
Ronstan
Ronstan Wide Dee Shackles [Pack of 2]
RF639: Stainless Steel Wide D Shackle, 5/32" Pin, Coined Head
SPECIFICATIONS
- Weight (g) 70
- P.L. B.L. (kg) 1700
- U.D.L. B.L. (kg) 3400
- A (mm) 7.9
- B (mm) 51.0
- C (mm) 28.0
- 5/16" pin dia., coined pin head
RF640: Stainless Steel Wide D Shackle, 3/8" Pin, Coined Head
SPECIFICATIONS
- Weight (g) 95
- P.L. B.L. (kg) 3600
- U.D.L. B.L. (kg) 5400
- A (mm) 9.5
- B (mm) 56.0
- C (mm) 29.0
- 3/8" pin dia., coined pin head
RF641: Stainless Steel Wide D Shackle, 1/2" Pin, Coined Head
SPECIFICATIONS
- Weight (g) 170
- P.L. B.L. (kg) 5500
- U.D.L. B.L. (kg) 7700
- A (mm) 12.7
- B (mm) 68.0
- C (mm) 33.0
- 1/2" pin dia., coined pin head. Shackle pins drilled for seizing wire.
Notes: UDL BL – The “Uniformly Distributed Load” breaking load of the shackle; the load is applied across the full span of the shackle pin. PL BL – The “Point Load” breaking load of the shackle; the load is only applied at the centre or one side of the shackle pin.
FEATURES
- High strength to weight ratio
PRODUCT INFORMATION
- 5/16" pin dia., coined pin head
APPLICATIONS
- Ideal for mainsheet, halyard and spinnaker sheet applications on boats to 11m (36ft).
- Various control line applications on larger yachts.
- Alloy sheave models are available for use with wire.
MATERIALS
- Grade 316 stainless steel bodies and pins
