Harken 60 Self-Tailing Performa Winch - 3 Speed (60.3STP)

Harken 60 Self-Tailing Performa Winch - 3 Speed

Harken
SKU:
60.3STP
|
UPC:
097653602842
$11,240.45
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

This is a Special Order item. Please contact sales@adventuresafety.com.au for availability and delivery lead time.

All Performa™ winches feature sandblasted drums optimized for halyard and sheeting applications using small-diameter, high-tech line. Self-tailing winches have narrow composite jaws to ensure superior holding power on small-diameter line. The self-tailing mechanism on the winch means that one crew member can quickly and easily trim or raise sails.

Part no. 60.3STP: 60 Self-Tailing Performa™ Winch - 3 Speed

Specifications

  • Weight (lb) 25.8 lb
  • Maximum line Ø (mm) 16 mm
  • Maximum line Ø (in) 5/8 in
  • Fasteners (mm) M8 SH mm
  • Fasteners (in) 5/16 SH in
  • Fastener circle (mm) 204 mm
  • Fastener circle (in) 8 in
  • Minimum line Ø (mm) 8 mm
  • Minimum line Ø (in) 5/16 in
  • Height (mm) 253 mm
  • Height (in) 10 in
  • Number of fasteners 6
  • Configuration Self-tailing
  • Speed 3
  • Drum Ø (mm) 120 mm
  • Drum Ø (in) 4 3/4 in
  • Base Ø (mm) 236 mm
  • Base Ø (in) 9 5/16 in
  • Line entry height (mm) 116 mm
  • Line entry height (in) 4 9/16 in
  • Gear ratio - 1   2.20
  • Gear ratio - 2   4.80
  • Gear ratio - 3   14.40
  • Power ratio - 1   9.20
  • Power ratio - 2   20.30
  • Power ratio - 3   61.00
