RWB Jabsco Par-Max HD5 Fresh Water Press Pump - 12v, 60psi, 19lpm

Jabsco Par Max 5 HD 12v Fresh Water Press Pump 60psi 19lpm
J20-280 Jabsco P501J-118S-3A

These Heavy Duty (HD) Par-Max 5 freshwater pressure pumps off er robust construction and high performance. These new modern design pumps have a 5 chamber diaphragm with reinforced polypropylene pumphead and off er pressure up to 60PSI.

These heavy Duty (HD) models include a heavy duty wider diameter motor with a powder coated shell, cast aluminium end bells and lower housing - to improve pressure capability and offer longer life and exceptional performance.

The ideal robust heavy duty pump for providing freshwater automatically to up to 4 x 20mm outlets on pleasure craft up to approx the 15 metre (50 Ft) range. Includes a 40 mesh plug-in universal inlet strainer in the box with the pump.

HD 5 chamber automatic pressure pump gives flow up to 5 US Gallons per minute (19 litres per minute) and pressure up to 60 PSI. Serves up to 4 x 20mm outlets onboard including galley, shower and additional faucets.

The Par-Max 5.0 HD gives very smooth water flow even at low demand due to its built-in pulsation dampening by-pass valve which controls unwanted cycling and reduces noise.

Inlet fi lter, corrosion resistant motor, soft rubber vibration dampening mounts and 4 x quick connect plug-in hose ports included - 2 x 12mm & 2 x 20mm barbed for hose. Uses standard size Jabsco plug-in ports.

12 volt ONLY - in 40PSI or 60 PSI cut-out pressure versions

Features and Benefits

• Fully automatic operation with integrated sealed pressure switch
• Pressure switch 40PSI or 60PSI cut off
• High capacity fl ow up to 19 litres 5 US gallons per minute
• Serves up to 4 x 20mm outlets on board simultaneously
• Modern 5 chamber design gives ultra smooth fl ow and quiet operation
• Built-in internal by-pass lowers water pulsation
• Self primes to 2.4 metres (8 feet)
• Can be installed vertically or horizontally
• Can be run dry for short periods without damage
• Powerful heavy duty ignition protected motor with thermal protection TCO
• Vibration dampening base plate & feet for quiet effi cient operation
• Available in 12 volt only in both 40PSI & 60PSI versions

Specifications

• Output up to 19 litres / minute (5 GPM) at open flow
• Pressure switch cuts in at ca. 3,2 bar (45 psi) and cuts out at 4,1 bar (60 psi)
• 5-chamber Santoprene diaphragm and EPDM valves
• Typically used for potable water systems with 4 or more outlets
• Self-Priming up to 1,8m
• Runs dry without damage
• Equipped with a bypass which enables smoother flow and decreases cycling
• Including straight snap-in ports 2 x 13mm (1/2") and 2 x 19mm (3/4") hose barb as well as 1 x 40 MESH strainer
• Amperage max. 12A; fuse size 20A
• Dimensions: Height 11,9 cm / width 12,7 cm (exlcuding hose ports) / length 24,5 cm
• Alternative to Jabsco 82500-0092, P501J-118S-3A
