Wichard Self-locking Bow Shackles (1241-1248)

Wichard Self-locking Bow Shackles (packs)

Wichard
SKU:
1241-1248
|
UPC:
3587790012415
$43.25 - $284.75
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

Wichard self-locking bow shackles

  • Self-locking bow shackle forged in grade 316L stainless steel
  • The pin is locked into one of the indentations
  • No risks of loose due to vibrations
  • Outstanding working and breaking loads
  • WLL: only for industrial applications (lifting i.e…)
  • CE marking and batch number

Applications

  • To be used when ample room is required
  • Possibility to attach several lines or cables

Materials

  • 316 stainless steel grade

Specifications

Part # Weight Working Load Breaking Strength Inside Length Inside Width Pin Diameter
kg lbs kg lbs kg in mm in mm in mm
1241 0.009 705 320 1543 700 0.71 18 0.31 8 0.16 4
1242 0.017 882 400 2205 1000 0.91 23 0.39 10 0.20 5
1243 0.030 1323 600 3307 1500 1.10 28 0.47 12 0.24 6
1244 0.068 2205 1000 5952 2700 1.46 37 0.63 16 0.31 8
1245 0.137 3351 1520 9480 4300 1.85 47 0.79 20 0.39 10
1246 0.233 4586 2080 13228 6000 2.17 55 0.94 24 0.47 12
1247 0.540 7055 3200 22046 10000 2.76 70 1.26 32 0.63 16
1248 1.056 8818 4000 33069 15000 3.15 80 1.57 40 0.79 20
