443-303-01: END CONTROL SINGLE SHEAVE, SYSTEM 30 PERF.

Selden System 30 Performance End Controls

Selden
SKU:
S443-303-01 to S443-304-02
$280.90 - $507.95
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

System 30 Performance can be used for boats up to approximately 45'.  Ideal when low friction and high purchase ratios are key requirements.

Technical Features of System 30 Performance

  • Torlon® ball bearing cars.
  • All cars, end controls and sheave houses are black anodised extruded aluminium.
  • Ø 30/40/50 mm trim sheaves with Torlon® ball bearings.
  • Cam cleat 38 used for main sheet car and end controls.
  • The toggle/sheet block is supported by a rubber stand-up collar.
  • The main sheet sheave has a plain bearing for vertical loads and Torlon® ball bearings stabilize the sheave when subjected to side loads.
  • Ø 60 mm plain bearing Acetal sheave in the genoa car.
  • Suitable max size of trim line is Ø 8 mm.
  • AISI 316 mirror finished stainless toggles for Seldén PBB 60, PBB 70 and RBB 60 blocks.
  • End controls with rubber shock absorbers and integral beckets for trim lines.
  • Genoa car has an integrated becket for rubber cord or to connect two cars.
  • The sheave house of the genoa car is made of AISI 316 mirror finished stainless steel.

Specifications

443-303-01: END CONTROL SINGLE SHEAVE, SYSTEM 30 PERF.

  • Weight: 229.00 g

  • System: 30p
  • Purchase: 4 N:1
  • Length: 95 mm
  • Width: 53 mm

443-303-02: END CONTROL DOUBLE SHEAVE, SYSTEM 30 PERF.

  • Weight: 295.00 g

  • System: 30p
  • Purchase: 6 N:1
  • Length: 95 mm
  • Width: 53 mm

443-304-02: END CONTROL DOUBLE FIDDLE, SYSTEM 30 PERF.

  • Weight: 390.00 g

  • System: 30p
  • Purchase: 8 N:1
  • Length: 130 mm
  • Width: 53 mm
