Harken Dinghy Vang Kit (HK431)

Harken Dinghy Vang Kit

Harken
SKU:
HK431
|
UPC:
097653288510
$487.71
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

This is a Special Order item. Delivery lead time may take 3-4 weeks.

The dinghy vang features 16 mm sheaves with stainless ball bearing for high loads. The assembly includes a 468 Micro Cam-Matic® cleat that allows precise trimming. It’s easy to cleat because it pivots for a fair lead. The unit connects to a mast bracket with a 1/4" pin. The system provides a 12:1 purchase when cascaded with 4:1 blocks. The kit includes a 16 mm double block cascaded to a Micro single with becket for the vang purchase, plus a Micro single for attaching the cunningham.

Part Number: 431

Specifications

  • Weight (g) 291 g
  • Weight (oz) 10.3 oz
  • Maximum working load (kg) 181 kg
  • Maximum working load (lb) 400 lb
  • Breaking load (lb) 1000 lb
  • Breaking load (kg) 454 kg
  • Maximum sail area (m²) 11.6 m²
  • Maximum sail area (ft²) 125 ft²


Resources/References:

Need help to design your Harken system - take a look here for the Harken System Diagrams

And here for Harken Manuals & Support Information
