Ronstan Series 125 Orbit Block, Single, High Load (RF129100A)

Ronstan Series 125 Orbit Block, Single, High Load

Ronstan
SKU:
RF129100A
|
UPC:
9316800493876
$1,424.77
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

RF129100A: SERIES 125 ORBIT BLOCK™, SINGLE
Single Sheave Block with Lockable Swivel Shackle Head

FEATURES

  • The highest strength-to-weight ratio.
  • Minimal friction loss, especially when working at high loads.
  • Totally reliable and trouble free performance.
  • Simplicity of design and construction to facilitate maintenance and servicing.
  • Elegant, functional styling and finish.

SPECIFICATIONS

  • B.L. (kg) 12000
  • M.W.L. (kg) 6000
  • Max. Rope diameter (mm) 18
  • Weight (g) 1240
  • Pin Ø (mm) 12.7

PRODUCT INFORMATION

  • Orbit Blocks™ are a no-compromise product range developed to meet the demands and expectations of the very dedicated and increasingly professional racing sailor.
  • Side cheeks incorporating head structure and hub are precision machined as a single part from solid alloy, leaving material only where it contributes to the load carrying capacity of the block and eliminating the need for additional fasteners.
  • The Orbit sheave has captive acetal or Torlon® ball bearings for side thrust loads, eliminating the need for side retainer plates. This reduces weight and allows for a wider bearing surface that can accommodate longer Torlon® needles – achieving a substantially higher strength-to-weight ratio.

MATERIALS

  • Fully machined Alloy cheek plates
  • Alloy sheaves with captive ball races
  • Torlon® needle rollers
  • Carbon black Acetal ball bearings
