Wichard Stainless Steel Wire Block for Aluminium Sheave (31024, 30036, 30050, 30070)

Wichard Stainless Steel Wire Block for Aluminium Sheave

Wichard
SKU:
30036-31024
|
UPC:
3587790310245
$44.85 - $155.55
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

WICHARD STAINLESS STEEL SINGLE BLOCKS  - ALUMINUM SHEAVE FOR WIRE BLOCK

  • Complete range of stainless steel blocks for dinghies
  • Lightweight, reliable and good performance
  • Available in a wide range of size and fastening systems

APPLICATIONS

  • Wire halayards, vangs, various control lines

MATERIALS

  • Aluminium sheave
  • 316L stainless steel grade cheeks

SPECIFICATIONS

Part no. 31024: Stainless steel single block - Alu sheave 24 - For 3 mm wire

  • Rope size 3 mm
  • Length (mm) 42
  • Width (mm) 25
  • Thickness (mm) 11
  • Working load (kg) 140
  • Breaking load (kg) 350
  • Weight (g) 19

Part no. 30036: Stainless steel single block - Alu sheave 36 - For 4 mm wire

  • Rope size 4 mm
  • Length (mm) 66
  • Width (mm) 39
  • Thickness (mm) 11
  • Working load (kg) 200
  • Breaking load (kg) 500
  • Weight (g) 50

Part no. 30050: Stainless steel single block - Alu sheave 50 - For 5 mm wire

  • Rope size 5 mm
  • Length (mm) 75
  • Width (mm) 50
  • Thickness (mm) 12
  • Working load (kg) 320
  • Breaking load (kg) 800
  • Weight (g) 84

Part no. 30070: Stainless steel single block - Alu sheave 70 - For 7 mm wire

  • Rope size 7 mm
  • Length (mm) 105
  • Width (mm) 70
  • Thickness (mm) 15
  • Working load (kg) 1200
  • Breaking load (kg) 2500
  • Weight (g) 222

Part no. 30071: Stainless steel single block - Alu sheave 70 -Swivel - For 7 mm wire

  • Rope size 7 mm
  • Length (mm) 150
  • Width (mm) 70
  • Thickness (mm) 15
  • Working load (kg) 1200
  • Breaking load (kg) 2500
  • Weight (g) 298
