Ronstan Series 50 High Load Block, Single (RF50100HL)

Ronstan Series 50 High Load Block, Single

Ronstan
SKU:
RF50100HL
|
UPC:
9316800241453
$93.39
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

RF50100HL: SERIES 50 HIGH LOAD BLOCK, SINGLE
Single, universal head

FEATURES

  • Exceptionally high working loads.
  • Lightweight.
  • Suitable for both rope or wire
  • Captive Lock™ universal head.
  • Slotted pin shackle eliminates fouled lines

SPECIFICATIONS

  • B.L. (kg) 1500
  • M.W.L. (kg) 750
  • Max. Rope diameter (mm) 12
  • Weight (g) 117
  • Pin Ø (mm) 5
  • A (mm) 4.6
  • B (mm) 6.5
  • C Max. (mm) 165.0
  • C Min. (mm) 110.0

PRODUCT INFORMATION

  • Ideal for high load applications.
  • Wear resistant sheave material, in lightweight, self lubricating polymer, is suitable for use with rope or wire.
  • Captive Lock™ universal head can be fixed in either of two planes, or free to swivel as required.

MATERIALS

  • Nylatron® sheave
  • Grade 316 stainless steel load strap and head fitting
  • Impact and U.V. resistant, fibre reinforced Nylon cheeks
