Ronstan Snatch Block, Alloy Sheave, 173mm LOA, Trunnion Head (RF6741)

Ronstan Snatch Block, Alloy Sheave, 173mm LOA, Trunnion Head

Ronstan
SKU:
RF6741
|
UPC:
9316800226337
$340.16
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

RF6741: SNATCH BLOCK ALLOY SHEAVE 173mm LOA
Single, roller bearings, trunnion snap shackle head

FEATURES

  • Easily operated latch mechanism.
  • Lightweight.
  • Soft resilient cheeks reduce clatter and protect gelcoat and painted surfaces.
  • Snap shackle head allows block to swivel through 360 degrees.

SPECIFICATIONS

  • Sheave diameter (mm) 45
  • B.L. (kg) 2550
  • M.W.L. (kg) 1275
  • Max. Rope diameter (mm) 16
  • Weight (g) 610
  • Sheave Material: Hardcote anodised aluminium

PRODUCT INFORMATION

  • Trunnion snap shackle provides the same swivel action and offers additional articulation from side to side
  • Spare Parts; RF6262 Replacement Plunger Pin Kit

APPLICATIONS

  • Removable spinnaker sheet deflector blocks for boats up to 1m (33ft).
  • Temporary sheeting point while changing sheets for boats up to 1m (33ft).
  • Temporary reefing block for boats up to 1m (33ft).
  • Spare or replacement block for general use on larger boats depending on line angle and load.
  • Temporary outboard sheet lead for headsail trimming.

MATERIALS

  • Grade 316 stainless steel frame, load strap and needle roller bearings.
  • Hardcote anodised alloy sheave.
  • Soft PVC cheeks.
  • Investment cast Grade 15-5PH stainless steel snap shackle
