Ronstan Series 60 Ratchet, Pivoting Low Lead (RF62174)

Ronstan Series 60 Ratchet, Pivoting Low Lead

Ronstan
SKU:
RF62174
|
UPC:
9316800217267
$342.55
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

RF62174: SERIES 60 RATCHET PIVOTING LOW LEAD BLOCK, SINGLE
Single Pivoting Low Lead Block with Ratchet

FEATURES

  • Unrivalled 20:1 holding power.
  • Dual-sided On-Off switch.
  • Ability to operate On-Off switch under load.
  • Low friction ball bearing system.
  • Lightweight.
  • Cheek cut-outs for easy bearing maintenance.

SPECIFICATIONS

  • Sheave diameter (mm) 60
  • B.L. (kg) 1370
  • M.W.L. (kg) 250
  • Max. Rope diameter (mm) 10
  • Weight (g) 147
  • Fastener Ø (mm) 5
  • Notes: Requires 4 x 5mm (3/16) fasteners

PRODUCT INFORMATION

  • The patented extruded hole design, in conjunction with the groove profile of the sheave, provides a more powerful grip than conventional designs - up to 20:1 holding power.
  • Unrivalled low weight is achieved by the use of a Torlon® ratchet pawl, high-grade machined alloy sheave and black Acetal hubs and bearings.
  • ON-OFF switching knob is fitted to both sides of the swivel blocks (one can be removed if desired).
  • Ratchet blocks can be disassembled for sheave replacement with RF62000.

APPLICATIONS

  • Mainsheet on powerful dinghies and skiffs
  • Control line applications on larger yachts
  • Spinnaker sheets on sportsboats and small keel boats (lateral lead blocks)

MATERIALS

  • Ball bearings: High compression strength acetal
  • Sheave and cheek plates: Anodised aluminium
  • Ratchet pawl: High strength Torlon®
