Wichard Plain Bearing Block Single Cheek (60120/61120)

Wichard Plain Bearing Block Single Cheek (packs)

Wichard
SKU:
60120-65120
|
UPC:
3587790601206
$38.62 - $66.90
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

WICHARD SINGLE PLAIN BEARING BLOCKS - CHEEK BLOCK

  • Complete range of plain bearing blocks
  • Modern design > Withstand high loads
  • Ideal for static operations
  • The sheave runs on the stainless steel bush
  • Light cheeks protecting the sheave
  • Wide choice of fastenings thanks to the universal head
  • The sheave can be removed for maintenance (60120/61120)

APPLICATIONS

  • Part nos. 60120/61120
    • For dinghies and catamarans applications: genoa sheets, boom vang, footmast block, masthead block…
    • For larger yachts: barber-hauler, cunnigham, various, control lines
  • Part nos. 63120-65120
    • Cheek blocks applications for genoa sheet

MATERIALS

  • Part nos. 60120/61120
    • Grade 316L stainless steel head configuration
    • Grade 316L stainless steel load straps
    • Polycarbonate cheeks
    • Composite sheave
  • Part nos. 63120-65120
    • Grade 316L stainless steel head configuration
    • Grade 316L stainless steel load straps
    • POM cheeks
    • Composite saddle for cam models
    • Composite sheave
    • Terminal (shackle i.e.): 316L stainless steel grade

SPECIFICATIONS

Part no. 60120: Single plain bearing block - Sheave 18 - cheek block

  • Rope size: 4
  • Length (mm): 36
  • Width (mm): 18
  • Thickness (mm): 14
  • Sheave diameter (mm): 18
  • Working load (kg): 240
  • Breaking load (kg): 500
  • Weight (g): 10

Part no. 61120: Single plain bearing block - Sheave 25 - Cheek block

  • Rope size: 6
  • Length (mm): 52
  • Width (mm): 25
  • Thickness (mm): 18
  • Sheave diameter (mm): 25
  • Working load (kg): 320
  • Breaking load (kg): 600
  • Weight (g): 21

Part no. 62120: Single plain bearing block - Sheave 35 - Cheek block M6

  • Rope size: 8
  • Length (mm): 52
  • Width (mm): 37
  • Thickness (mm): 20
  • Sheave diameter (mm): 35
  • Working load (kg): 320
  • Breaking load (kg): 900
  • Weight (g): 44

Part no. 63120: Single plain bearing block - Sheave 45 - Cheek block M6

  • Rope size: 10
  • Length (mm): 65
  • Width (mm): 49
  • Thickness (mm): 23
  • Sheave diameter (mm): 45
  • Working load (kg): 400
  • Breaking load (kg): 900
  • Weight (g): 73

Part no. 64120: Single plain bearing block - Sheave 55 - Cheek block M6

  • Rope size: 12
  • Length (mm): 81
  • Width (mm): 63
  • Thickness (mm): 26
  • Sheave diameter (mm): 55
  • Working load (kg): 720
  • Breaking load (kg): 1500
  • Weight (g): 123

Part no. 65120: Single plain bearing block - Sheave 70 - Cheek block - M8

  • Rope size: 14
  • Length (mm): 103
  • Width (mm): 80
  • Thickness (mm): 34
  • Sheave diameter (mm): 70
  • Working load (kg): 1200
  • Breaking load (kg): 2700
  • Weight (g): 294
