Harken Crossbow Self-Tacking Jib System - 1100mm Long x 50mm
The Crossbow™ is a self-tacking jib system designed for high-performance dinghies, skiffs, and catamarans under six meters (20 feet). The system features a curved track that hinges to align both car and track with the sheet loads for less friction, more load-bearing capacity, and for an ultra-lightweight design.
The two-piece car body is machined of 6061-T6 aluminum and Hard Lube-anodized for strength and corrosion resistance. Curved races evenly distribute the loads on Torlon® ball bearings for low-friction rolling. A Delrin® cap keeps the balls captive when the car is removed from the track.
The hardcoat-anodized track has three pivoting attachment points that distribute the load. Track is offered in 20 or 50 mm heights. Use 50 mm track with a single-line spinnaker system. The track’s center strut has a hole for a fair, chafe-free halyard lead. Torlon is a registered trademark of Solvay Advanced Polymers L.L.C. Delrin® is a registered trademark of E. I. du Pont de Nemours and Company or its affiliates.
Specifications
- Width (mm) 50 mm
- Width (in) 1 31/32 in
- Weight (oz) 28.3 oz
- Weight (kg) 0.8 kg
- Fasteners (mm) 5 FH mm
- Fasteners (in) #10 FH in
- Length (m) 1.1 m
- Length (ft in) 3' 7 5/16" ft in
- Fastener spacing (in) 21 13/16 in
- Fastener spacing (mm) 554 mm
Resource/Reference:
Crossbow™ Pivoting Self-Tacking Jib System Manual
Need help to design your Harken system - take a look here for the Harken System Guides and Drawings
Or perhaps you need some other information (load calculators, block selectors, service instructions or manuals)? Take a look here for all the official Harken Support Information
