Harken 75 mm Tulip Over-the-Top Block (HK9035)

Harken 75 mm Tulip Over-the-Top Block

Harken
SKU:
HK9035
|
UPC:
097653298045
$755.00
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

This is a Special Order item. Please contact sales@adventuresafety.com.au for the delivery lead time and availability.

Designed to facilitate full 90 degree deflections in rope path, facilitating horizontal to vertical transitions over cabintops to cockpit floors on offshore catamarans. Their unique divides design allows for one line to be substituted for another in the middle of a system rather than requiring a complete re-rig through a rope clutch.

Part no. 9035:  75 mm Tulip Over-the-Top Block

Specifications

  • Sheave Ø (mm) 75 mm
  • Sheave Ø (in) 2 5/16 in
  • Length (mm) 116 mm
  • Length (in) 4 9/16 in
  • Width (mm) 66 mm
  • Width (in) 2 9/16 in
  • Height (mm) 65 mm
  • Height (in) 3 7/8 in
  • Weight (g) 830 g
  • Weight (oz) 29 oz
  • Maximum line Ø (mm) 14 mm
  • Maximum line Ø (in) 9/16 in
  • Number of fasteners 3
  • Fasteners (mm) 10 mm
  • Fasteners (in) 3/8 in
  • Maximum working load (kg) 3629 kg
  • Maximum working load (lb) 8000 lb
  • Breaking load (lb) 16000 lb
  • Breaking load (kg) 7257 kg
