Ronstan Halyard Shackles
Ronstan
$23.23 - $66.66
(No reviews yet)
Write a Review
Ronstan
Ronstan Halyard Shackles
HALYARD SHACKLES
Halyard shackles have a lever action for esay opening and closing, with a keyed pin for positive locking.
FEATURES
- High strength to weight ratio
MATERIALS
- Grade 316 stainless steel bodies and pins
SPECIFICATIONS
| HALYARD SHACKLES | ||||||||
| Product No. | Description | A (mm) | B (mm) | C (mm) | D (mm) | PL/BL (kg) | UDL/BL (kg) | Weight (g) |
| RF1032 | Halyard Shackle, Pin 3/16” | 4.8 | 22 | 10.5 | 15 | 900 | 1200 | 30 |
| RF1033 | Halyard Shackle, Pin 1/4” | 6.4 | 32 | 13.0 | 19 | 1500 | 2100 | 55 |
| RF1034 | Halyard Shackle, Pin 5/16” | 7.9 | 39 | 18.5 | 20 | 2200 | 2700 | 90 |
NOTES
- UDL BL – The “Uniformly Distributed Load” breaking load of the shackle; the load is applied across the full span of the shackle pin. PL BL – The “Point Load” breaking load of the shackle; the load is only applied at the centre or one side of the shackle pin.
