Ronstan Two Way Links [Pack of 2]
Ronstan
$96.16 - $97.06
(No reviews yet)
Write a Review
Ronstan
Ronstan Two Way Links [Pack of 2]
RF815: Two Way Link, 5mm
To suit RS006000, RS006010
SPECIFICATIONS
- 5mm (3/16")
- Weight (g) 14
- P.L. B.L. (kg) 900
- U.D.L. B.L. (kg) 1100
- A (mm) 5.0
- B (mm) 5.2
- C (mm) 10.0
- D (mm) 5.5
RF816: Two Way Link, 6mm
SPECIFICATIONS
- Weight (g) 21
- P.L. B.L. (kg) 1000
- U.D.L. B.L. (kg) 1200
- A (mm) 6.0
- B (mm) 6.7
- C (mm) 12.2
- D (mm) 7.0
Notes:
- UDL BL – The “Uniformly Distributed Load” breaking load of the shackle; the load is applied across the full span of the shackle pin.
- PL BL – The “Point Load” breaking load of the shackle; the load is only applied at the centre or one side of the shackle pin.
MATERIALS
- Grade 15-5PH investment cast stainless steel body and hasp
- Grade 316 stainless steel plunger pin and spring
- RF68 grade 316 stainless steel
