Harken 40mm Carbo Fixed Double Block
Harken
$144.04
(No reviews yet)
Write a Review
Harken
Harken 40mm Carbo Fixed Double Block
Low-friction Carbo Air blocks are lightweight, strong, reliable—and affordable. Companions to the popular Harken Big Boat blocks, these small, compact blocks have very high working loads for safe, easy trimming.
Part no. 2642: 40mm Carbo Air Double Block
Specifications
- Sheave Ø (mm) 40 mm
- Sheave Ø (in) 1 9/16 in
- Length (mm) 89 mm
- Length (in) 3 1/2 in
- Weight (g) 80 g
- Weight (oz) 2.8 oz
- Shackle pin Ø (mm) 5 mm
- Shackle pin Ø (in) 3/16 in
- Maximum line Ø (mm) 10 mm
- Maximum line Ø (in) 3/8 in
- Maximum working load (kg) 440 kg
- Maximum working load (lb) 970 lb
- Breaking load (kg) 1080 kg
- Breaking load (lb) 2380 lb
